Khoom Description
FM200 Tag Nrho Cov Hluav Taws Xob Hluav Taws Xob Hluav Taws Xob yog qhov ua tau zoo, huv si, thiab nrawm- ua cov tshuaj tiv thaiv hluav taws tsim los rau thaj chaw uas muaj txiaj ntsig thiab kev ua haujlwm muaj kev pheej hmoo ntawm hluav taws. FM200, tseem hu ua Heptafluoropropane (C3HF7), yog xim tsis muaj xim, tsis muaj ntxhiab, thiab hluav taws xob tsis muaj hluav taws xob -cov pa hluav taws xob uas tua hluav taws sai sai yam tsis muaj qhov seem seem. Cov kab ke no tau siv dav hauv cov chaw khaws ntaub ntawv, chav neeg rau zaub mov, chaw sib txuas lus, thiab lwm qhov chaw tseem ceeb uas tsis tshua muaj kev poob qis thiab kev tiv thaiv khoom vaj khoom tsev yog qhov tseem ceeb.
Nta:
Rapid Fire Suppression:FM200 tuaj yeem tua hluav taws tsis pub dhau 10 vib nas this ntawm kev tshawb pom, txo qis kev puas tsuaj thiab txo qis sijhawm.
Tus neeg saib xyuas huv:Raws li tus neeg sawv cev gaseous, FM200 tawm tsis muaj qhov seem tom qab, tshem tawm qhov xav tau kev tu tus nqi tom qab tso tawm.
Safe rau cov neeg nyob:FM200 muaj kev nyab xeeb rau cov chaw nyob thaum siv nyob rau hauv cov qauv tsim, ua rau nws zoo tagnrho rau kev siv hauv kev lag luam thiab kev lag luam.
Environmentally Friendly:FM200 muaj xoom ozone depletion muaj peev xwm (ODP) thiab lub neej luv ntawm atmospheric lifetime, ua rau nws xaiv ib puag ncig zoo dua piv rau lwm cov neeg tua hluav taws.
Kev sib koom ua ke yooj yim:FM200 system tuaj yeem ua ke nrog cov khoom siv hluav taws xob uas twb muaj lawm thiab lub tswb nrov, kom ntseeg tau tias muaj kev tiv thaiv hluav taws.
Txoj Cai Ua Haujlwm
Txoj Cai Ua Haujlwm:
FM200 Total Flooding System ua haujlwm raws li lub hauv paus ntsiab lus yooj yim thiab siv tau:
Kev Ntsuas Hluav Taws Xob:Lub kaw lus tau nruab nrog cov pa luam yeeb thiab cov ntsuas cua sov uas tsis tu ncua saib xyuas thaj chaw tiv thaiv. Thaum pom qhov hluav taws kub, lub kaw lus cia li qhib.
Tus neeg sawv cev tso tawm:Thaum ua haujlwm, tus neeg sawv cev FM200 tau tawm sai sai los ntawm cov thooj voos kheej kheej los ntawm kev sib txuas ntawm cov kav dej. Cov roj sib npaug sib npaug thoob plaws hauv qhov chaw tiv thaiv, ua kom muaj kev tiv thaiv tiav.
Hluav Taws Xob:FM200 tua hluav taws feem ntau los ntawm kev nqus cua sov. Cov pa roj absorbs cua sov lub zog los ntawm hluav taws, txo qhov kub thiab txias mus rau qhov chaw uas combustion tsis tuaj yeem txuas ntxiv. Tsis tas li ntawd, FM200 cuam tshuam nrog cov tshuaj tiv thaiv ntawm hluav taws, ntxiv inhibiting txheej txheem combustion.
Tshaj tawm - Tso tawm:Tom qab tua hluav taws, cov roj FM200 sai sai sai, tsis muaj qhov seem tom qab. Qhov no tso cai rau kev nkag mus rau thaj chaw tiv thaiv tam sim ntawd rau kev ua haujlwm rov qab thiab txo qhov cuam tshuam rau kev ua haujlwm.
Kev qhia tshwj xeeb
Tag Nrho Hluav Taws System Specification:
kev sib piv ntawm cov khoom parameter
| Filling Siab | 2.5 Mpa |
| Max Ua Haujlwm Siab | 4.2Mpa |
| Muaj peev xwm ntawm FM200 Lub tog raj kheej | 70L 90L 120L 150L 180L |
| Khoom siv ntawm lub tog raj kheej | Hlau, Stainless hlau |
| Filling Ceev | 1.13 |
- ---1. Specification ntawm lub tog raj kheej
Hlau cylinder thiab Stainless hlau cylinder
Cylinder's Specificaiton
| Yam khoom | Muaj peev xwm | Xov | Txoj kab uas hla | Thickness | Max ua haujlwm siab |
| 1 | 70L | PZ56/2-8UN.2A | 300 | 4 | 4.2Mpa |
| 2 | 90L | PZ56/3-1/4''-8UN.2A | 350 | 4.5 | 4.2Mpa |
| 3 | 120L | PZ64X2/3-1/4''-8UN.2A | 350 | 4.5 | 4.2Mpa |
| 4 | 150L | PZ64X2/3-1/4''-8UN.2A | 400 | 5 | 4.2Mpa |
| 5 | 180L | PZ80X2/3-1/4''-8UN.2A | 400 | 5.5 | 4.2Mpa |
---2. Specification ntawm Valve
Zoo li qub & High Quality
rau Normal Quality VALVE
| Yam khoom | DN 32 | DN40 | DN 50 |
| Code NO. |
V32/4.2-PRI |
V40/4.2-PRI |
V50/4.2-PRI |
| Neck Xov | PZ56 | M64X2 | M80X2 |
| Actuator Xov | M18X1.5 | M18X1.5 | M18X1.5 |
| Diptube Xov | RC 1-1 / 4 '' | RC 1-1 / 2 '' | RC 2 '' |
| High Pressure saj zawg zog thread | M48X2 | M56X2 | M68X2 |
| Pressure gauge xov | M10x1 | M10x1 | M10x1 |
| Ua Haujlwm Siab | 4.2Mpa | 4.2Mpa | 4.2Mpa |
| Siv tau lub tog raj kheej | <=100L | 120L 150L | 180L |
Rau siab zoo VALVE
| Code No. |
AV 25 |
AV 50 |
| Yam khoom | G1'' | G2'' |
| caj dab xov | 2-8 UN.2A | 3 1/4-8UN.2A |
| Actuator xov | G1'' | G1'' |
| Kev kub siab hloov tau xov | G1'' | G2'' |
| Pressure gauge xov | 1/8 '' NPT | 1/8 '' NPT |
| Ua hauj lwm siab | 6.7mpa ua | 6.7mpa ua |
| Kuaj siab | 10.05 Mpa | 10.05 Mpa |
| Siv tau lub tog raj kheej | <=70L | 90L 120L 150L 180L |
--- 3. Nozzles:
rau nOZZLE
| Yam khoom | DN 25 | DN 32 | DN40 | DN 50 |
| Code No. | N25-PIB | N32-PIB | N40-PIB | N50-PIB |
| Xov | RC 1 '' | RC 1-1 / 4 '' | RC 1-1 / 2 '' | RC 2 '' |
| Khoom siv | tooj dag | |||
---4. High Pressure Yeeb Nkab, Kev Nyab Xeeb Valve rau Manifold Yeeb Nkab, Tsawg Tshaj Tawm High Kaw Valve, Liquid Check Valve, Gas Check Valve, Siab Hloov, Siab Ntsuas, thiab lwm yam.
--- Tswj vaj huam sib luag thiab hluav taws kub tswb System
Rau PRI-SAFETY FM200 Tag Nrho Flooding Fire System, Control Vaj Huam Sib Luag Thiab Hluav Taws Xob Hluav Taws Xob muaj qhov chaw nyob tswj vaj huam sib luag, ntsuas pa taws, ntsuas hluav taws xob, ntsuas hluav taws xob / pib hloov, pib thaum muaj xwm ceev / rho tawm khawm, tso tawm lub teeb, I / O Module, Tswb (Siren / Teeb).
Ntau lawm
Ntim
Tuam txhab Profile
Peb ib txwm nyob ntawm koj qhov kev pabcuam thaum koj xav tau
PRI-SAFETYFIRE TECHNOLOGY yogruaj khov nyob rau hauv 2005, yog tsom rau AutomaticFyogTxhaum Ssystem thiabFyogEkhoom sivR&D, Dkos npe thiabKev tsim khoom.
Cov khoom tseem ceeb yog On/Off RoadVehicles& TshuabTsis Siv Neeg Hluav Taws Xob Hluav Taws Xob, HFC-227ea & FK-5112 huvgasHluav Taws Xob Hluav Taws Xob Systems,CAFS(Mobile Compressed Air Foam System), Dej Ntshiab FQhov System,Ua npuas ncaujHluav Taws System,Co 2Hluav Taws System, lwm.
Cov Khoom Siv Hluav Taws Xob thiab Hluav Taws Xob yog siv hauv Kev Lag Luam Mining, Kev Lag Luam Hav Zoov, Kev Ua Liaj Ua Teb, Petrochemical, Tsheb thauj mus los, Hluav Taws Xob, Kev Lag Luam, Kev Tsim Kho thiab lwm yam.
PRI-SAFETYMuaj pab neeg ua haujlwm tshaj lij, muaj peev xwm muab khoomTsim, daws, thiab Customization,Rau Qhov Kev Xav Tau Tshwj Xeeb, thiab TechnologyKev cob qhia & kev qhiaTom qab Muag.
PRI-SAFETYMuaj Cov Ntawv Pov Thawj,ISO9001: 2015, TUV CE0036, ECE R107, CCC, thiab So On. Cov khoom ua tau raws li International Standard ntawmEN, NFPA, CNAS, ECE, lwm.
